MasterBMS
MasterBMS
Enables creation of a ready-made MasterSCADA 4D project for building engineering systems control.
A fundamentally new level of project creation for building dispatching systems.
-
Operation
in data centers -
Global
IT-solution -
Ranking top 5
SCADA-systems in Russia
Technological processes
Electrical Power Supply (Substation, Automatic Transfer Switch, Diesel Generator Set, Power Distribution Unit)
Heat Supply (Individual Heating Substation)
Main ventilation system
Lighting system
Environmental monitoring
Incident management
Uninterruptible power supply
AFSS (Automatic Fire Suppression System)
Utility accounting (AMRSEU)
Climate control and refrigeration
IT infrastructure monitoring
BIM integration
Water supply and drainage
Configurator
Hardware Support
Standardization
Performance outcome
Benefits
Flexibility
Benefits
Engineering systems optimization
Real-time building performance visualization
Integration with existing customer systems
User-friendly navigation
Multi-vendor equipment compatibility
Mitigation of accident risks and prompt reaction
Features
Design visualization and process control solutions for installations, workshops, and factories through a unified interface with MasterSCADA 4D — a robust platform for monitoring and control suitable for every production sector. Streamline the development of schematic diagrams using a powerful editor featuring typing support and object-oriented methodology. Harness extensive integration capabilities to create drivers and integration modules for interfacing with external systems.
-
Scalable Architecture
MasterSCADA 4D architecture supports projects ranging from small-scale local solutions to extensive distributed systems, with all tasks managed within a single project framework and common data environment
-
Cross-Platform Capability
The system supports Windows and Linux based platforms. All operating systems are supported across all management levels: PLCs, industrial PCs, operator workstations, servers, and cloud services.
-
Integrated Communication Protocols
The system provides complete OPC support (OPC UA, DA, HDA), facilitating seamless data exchange setup in automation systems. Its extensive range of built-in drivers supports direct connections to industrial equipment and PLCs from multiple manufacturers, eliminating the need for OPC.
-
Hot Spare
The adaptable structure of MasterSCADA facilitates the deployment of hot redundancy across all system nodes, guaranteeing rapid switchover and precise data synchronization.
-
Object-Oriented Project Approach
By leveraging encapsulation, inheritance, and replication mechanisms, the object-oriented project development approach substantially decreases system development and debugging time.
-
System Notifications
The comprehensive alert system provides instant access to detailed information about incidents and events, organized in a user-friendly journal with built-in filtering features. Integrated SMS, email, and Telegram notifications enable immediate response to critical situations.
-
Analytics Suite
The embedded trend analysis toolkit provides powerful means to examine variations in process parameters via charts and tables, ensuring comprehensive recovery of parameter behavior at any specified time.
-
Web-Based Visualization System
The visualization platform, built on HTML5, adheres to contemporary visualization trends. Web-based clients provide identical functionality to local graphical interfaces, maintaining consistency in both data representation and control features.
-
Detailed Reporting
Our embedded reporting editor facilitates the development of sophisticated report formats, incorporating graphical elements such as charts, histograms, and other visual components. Data sourcing is flexible, supporting both internal project data and external feeds, while advanced processing capabilities include formula calculations, filtering options, and customizable rules.
-
Secure Historical Data Retention
To store historical data (systems with up to 500 tags), MasterSCADA employs SQLite. For extensive projects, third-party databases are advised. MasterSCADA interacts with DBMS in three modes — archive, export, and stored procedures, supporting MS SQL and PostgreSQL.
-
Cyber Security
The system’s embedded information security tools deliver broad capabilities to ensure top-tier security for the operational facility. The security module operates through a unified management console with customizable user rights options. It includes functionality for creating and duplicating user templates. User actions can be logged via a specialized journal. Compatibility with Active Directory and LDAP is provided.
Manuals and data
Online Support Guide
Online Documentation featuring search and filtering options
Documentation
Software Download, Installation, and Upgrade Instructions
API MasterSCADA 4D
API for third-party application integration
Video
Detailed video tutorials and practical tips
FAQ
General questions about MasterSCADA 4D
Success stories
Discover how MasterSCADA 4D implementing has improved the efficiency of technological processes
System Requirements
Supported Operating Systems
References
Let's work together
for integration into our standardized solutions portfolio
